DESIGN/CONSTRUCT AN OIL AND GAS OFFICE - An Overview by Nik Zafri

 Acknowledgement:

I would like to express my sincere appreciation to my friends in the Oil and Gas industry for their valuable contributions, as well as to the sponsors for their generous support, which enables me to continue producing quality articles for everyone to read and share. To those who would like me to sponsor content featuring their company, or to promote products and services, or write on topics related to the construction industry, kindly share the relevant technical details, photographs, specifications, measurements, and any other supporting information.

For Article Sponsorship or Briefing/Visit/Consultancy - Scan the QR in the next column - provide receipts via PM/email

Designing and constructing an oil and gas office is not just about putting up a building, it is about creating a safe, resilient, and highly functional operational hub that can support one of the most demanding industries in the world. This is where an EPCC (Engineering, Procurement, Construction & Commissioning) approach becomes critical. It's a multidisciplinary challenge that goes far beyond architecture. It is about engineering confidence into every detail from structural integrity to human comfort.

With a strong EPCC framework, organisations can deliver facilities that are not only durable and efficient, but also aligned with the highest safety standards in the industry.

1. WHY EPCC?

An EPCC model ensures end-to-end accountability from concept design to final commissioning. In oil and gas environments, where risks are high and margins for error are low, EPCC helps to:

1.1 Incorporate Safety into Design From Day 1 - This is not a slogan. It is a structured process embedded in engineering workflows.

Key Practices : Hazard Identification and Risk Studies,

• Conduct HAZID (Hazard Identification) during concept stage

• Follow with HAZOP (Hazard and Operability Study) for detailed design

• Include QRA (Quantitative Risk Assessment) for facilities near process plants

Example: If the office is within a refinery perimeter, QRA may dictate:

• Minimum safe separation distance (e.g. 150–300 m from hydrocarbon units)

• Orientation of building away from potential blast sources

b. Blast-Resistant and Fire-Safe Design - Design in accordance with relevant API and ISO Standards/Guidelines

Apply blast load calculations (e.g. 0.3 - 1.0 bar overpressure depending on risk study)

Use:

• Reinforced concrete shear walls,

• Laminated, blast-rated glazing,

• Progressive collapse-resistant framing

Example : A control office near a gas processing plant may require:

• 2-hour fire-rated walls

• Overpressure-resistant doors

• No direct line-of-sight to high-risk equipment

c. Safe Layout and Egress Planning

• Minimum 2 means of escape per occupied zone,

• Travel distance limits (typically < 30–45 m depending on code)

Segregate : Admin areas, control rooms and Hazard interface zones

1.2 Procurement to Meet Industry Specs

Procurement in oil and gas is engineering-driven, not price-driven.

Key Controls

a. Approved Vendor List (AVL) & Prequalification

• Vendors must comply with: ISO 9001 (Quality) ISO 45001 (Safety)

• Conduct technical bid evaluation (TBE) before commercial review

b. Material Certification & Traceability

• Require: Mill certificates (EN 10204 3.1) Material Test Certificates (MTC)

• Full traceability from manufacturer to installation

Example: Structural steel for office:

• Meet ASTM A572/BS EN standards

• Coating: minimum C5-M corrosion protection for coastal facilities

c. Hazardous Area Equipment Compliance

• Use only certified equipment: ATEX/IECEx rated

• Especially for: Lighting fixtures HVAC systems Electrical panels near classified zones

d. Construction Quality and Compliance

Execution is where most failures occur even with good design.

Key Practices

a. Inspection & Test Plans (ITP)

• Define hold points and witness points

• Typical checks: Reinforcement inspection before concreting Concrete cube strength testing (7 & 28 days) Coating thickness (DFT measurement)

b. Quality Assurance/Quality Control (QA/QC)

• Follow project-specific Project Quality Plan (PQP)

• Maintain: Method Statements Work Inspection Requests (WIR) Non-Conformance Reports (NCR)

Example: Concrete works:

• Ensure proper vibration (avoid honeycombing)

• Cover blocks to maintain durability (e.g. 40–50 mm in aggressive environments)

c. Environmental & Site Compliance

• Dust, noise, and waste management

• Silt traps and drainage control (especially relevant in Malaysia’s heavy rainfall)

1.3 Validation and Commissioning

Commissioning is not just testing, it is proving operational readiness.

Process

Example: Control room scenario:

• Loss of power = UPS supports systems for 30 mins

• Generator kicks in within 10–15 seconds

No facility is complete without thorough commissioning, it's the final safety gate. In EPCC, this phase ensures:

• All systems operate as intended

• Safety systems are tested under real conditions

• Personnel are trained for operations and emergency response

It is the final assurance that the office is not only built well but is ready to perform safely from day one.

d. Operational Readiness

• SOPs (Standard Operating Procedures)

• Emergency Response Plan (ERP)

• Training and Competency assessment

Examples

For a remote upstream operations office:

These factors reduce fragmentation and aligns all stakeholders under a single responsibility framework crucial for safety and performance.

2.0 SAFETY AND DURABILITY

Oil and gas offices especially those located near processing plants, refineries, or offshore bases must withstand harsh environments:

2.1 Corrosive Atmospheres (Salt, Chemicals, Hydrocarbons)

Corrosion is not cosmetic, it is a structural and safety risk.

Exposure

• Coastal/offshore salt-laden air (chlorides)

• Acidic gases (H₂S, CO₂ = sour service)

• Hydrocarbon vapours and chemical splashes

• Industrial pollutants (SOx, NOx)

2.2 Design

a. Material Selection

• Structural steel: Use corrosion-resistant grades or apply protective systems

• Reinforced concrete: Low permeability mix (w/c ratio ≤ 0.40) Additives: silica fume, fly ash Increase cover (50–75 mm in severe exposure zones)

b. Protective Coating Systems

• References - NACE International/ISO 12944

• Typical system for C5-M (marine, high corrosion): Zinc-rich primer ეპoxy intermediate coat - Polyurethane topcoat

Example: External steel staircase near a coastal LNG plant:

• Design life: 15–25 years coating durability

• DFT (Dry Film Thickness): ~250–350 microns total

c. Cathodic Protection (CP)

• For buried or submerged components: Sacrificial anode systems Impressed current systems

d. Detailing Matters

• Avoid water traps and crevices

• Provide drainage holes

• Seal joints properly

Most corrosion failures occur at connections, bolts, and interfaces not main members.

2.3 High Temperatures and Potential Fire Exposure

In oil and gas, fire is not hypothetical, it is a design load case.

Risk

• Pool fires (liquid hydrocarbons)

• Jet fires (pressurized releases)

• Flash fires / explosions

2.4 Design (Fire)

a. Fire Resistance Ratings (FRR)

• Structural elements: Minimum 1–2 hours fire rating

• Use: Fireproofing (cementitious/intumescent coatings) Concrete encasement

b. Passive Fire Protection (PFP)

• Apply to: Structural steel Critical supports

• Designed per American Petroleum Institute and industry fire curves

Example: Steel column near process unit:

• Intumescent coating thickness designed for 2-hour protection at ~1000°C

c. Active Fire Protection Systems

• Fire detection: Smoke, heat, flame detectors

• Suppression: Sprinklers Deluge systems Foam systems (for hydrocarbon fires)

d. Thermal Expansion Consideration

• Provide: Expansion joints Sliding supports

• Prevent: Structural distortion Cracking in concrete

e. HVAC and Smoke Control

• Pressurised escape routes

• Smoke extraction systems

• Fire dampers in ducting

3.0 VIBRATIONS AND OPERATIONAL LOADS

Often overlooked in office design but critical near operating facilities.

3.1 Sources

• Rotating equipment (compressors, turbines),

• Heavy vehicle movement,

• Piping-induced vibration,

• Nearby blasting or drilling activities

3.2 Design (Vibrations)

a. Structural Design for Dynamic Loads

• Perform: Vibration analysis Modal analysis (natural frequency checks)

Goal: Avoid resonance between structure and equipment frequency.

b. Isolation Systems

Use: Vibration isolators (spring / rubber mounts) Floating floors for control rooms

Example: Control room near compressor station:

Floor isolation reduces vibration transmission = protects sensitive instruments

c. Equipment Foundation Design

• Separate foundations for: Heavy rotating equipment Office structure

• Use inertia blocks: Mass = 3–5× machine weight

d. Human Comfort Criteria

• Follow limits (e.g. ISO vibration standards): office spaces require very low vibration thresholds

Even when structurally safe, excessive vibration leads to:

• Staff fatigue

• Reduced concentration

• Equipment malfunction

e. Examples :

For an onshore gas processing facility office:

• Corrosion Control C5-M coating system Stainless steel fixtures in exposed areas

• Fire Protection 2-hour fire-rated structure Intumescent coating on steel Foam suppression system nearby

• Vibration Mitigation Control room on isolated slab Equipment on separate foundations

These three factors, corrosion, heat, and vibration, do not act independently.

They compound each other:

• Heat accelerates corrosion

• Vibration damages protective coatings

• Corrosion weakens fire resistance

Good engineering anticipates this interaction. Great EPCC execution designs for it from the start.

This all demands robust structural systems, high-grade materials, blast-resistant design considerations, and strict adherence to international standards such as API and ISO. Fire-rated assemblies, explosion-proof fittings, and well-planned evacuation routes are not optional, they are baseline requirements.

4.0 HIGH PERFORMANCE WORKSPACE

While safety is paramount, the human factor cannot be ignored. Today’s oil and gas offices are evolving into smart, ergonomic, and collaborative environments:

4.1 Digital Control Rooms with Real-Time Monitoring

4.2 Design Objectives

• Real-time visibility of plant operations

• Early anomaly detection

• Centralised decision-making

• High operator reliability under stress

4.3 Guidelines

a. Integrated SCADA/DCS Systems

• Deploy SCADA system and Distributed Control System (DCS) integration

• Ensure: Redundant communication networks (dual fibre / ring topology) Real-time data latency < 1–2 seconds for critical parameters

b. Control Room Ergonomics

• Follow ISO 11064 (Control Room Design)

• Requirements: Operator consoles with adjustable sight lines Maximum screen viewing angle ≤ 30° Acoustic control (≤ 55 dB ambient noise)

c. Visualization

• Large-format video walls (4K/8K)

• Alarm prioritisation: Red = safety critical Amber = operational warning Green = normal

Example : In a gas processing facility:

• Operators monitor: Pressure drop in pipelines. Compressor vibration Gas leak detection sensors

• System automatically triggers: Emergency shutdown (ESD) if thresholds exceeded

4.2 Flexible Workspace

Modern oil & gas offices are shifting from static layouts to adaptive, mission-based environments.

4.3 Design (Workspace)

a. Activity-Based Working (ABW)

Spaces designed by function, not hierarchy:

• Engineering zone (design + modelling)

• Data analytics zone

• Field coordination zone

• Collaboration hubs

b. Modular Workspace Design

• Movable partitions

• Plug-and-play power/data floors

• Hot-desking systems

c. Digital Infra

• High-speed secure networks (minimum 1–10 Gbps backbone)

• Secure VPN access for field engineers

• Cloud-based collaboration platforms

d. Example Layout

• Engineers: 3D modelling stations (BIM/CAD workstations)

• Analysts: dual-screen data dashboards

• Field teams: rugged tablets + docking stations for report uploads

e. Benefit

• Reduces idle space by 20–40%

• Improves cross-discipline collaboration speed

5.0 INTEGRATION OF IOT AND DATA FOR PREDICTIVE MAINTENANCE

This is where oil & gas offices evolve into data-driven operational intelligence centres.

Key Technologies

a. Industrial IoT (IIoT) Layer

• Sensors on: Pumps Compressors HVAC systems Electrical switchgear

Connected through Industrial Internet of Things (IIoT)

b. Data Pipeline Architecture

Typical flow:

c. Predictive Analystics

Use:

• Machine learning models for failure prediction

• Trend analysis (vibration, temperature, pressure)

d. Guidelines

• Sampling frequency: Critical equipment: 1–10 Hz

• Data redundancy: Minimum dual sensor validation

• Storage: Time-series database (historical and real-time)

Example :

A compressor shows:

• Increasing vibration trend over 3 weeks

• AI model predicts bearing failure in 10–14 days

Outcome:

• Maintenance scheduled during planned shutdown

• Avoids unplanned outage (cost saving: high impact)

e. Engineering Value

• Reduces downtime by 20–50%

• Extends asset life cycle

• Enables condition-based maintenance (CBM)

6.0 WELLNESS-FOCUSED DESIGN FOR HIGH STRESS ENVIRONMENT

Oil annd gas decision environments are high pressure, high consequence spaces.

a. Design (High-Stress Environment)

• Reduce cognitive fatigue

• Improve decision accuracy

• Enhance mental resilience

b. Guidelines

i) Lighting

• Use circadian lighting systems: 300–500 lux for focus work Tunable white light (4000K–6500K range)

• Minimise glare on screens (< 19% UGR rating)

ii) Acoustic

• Sound zoning: Silent zones (≤ 40 dB) Collaboration zones (≤ 55 dB)

• Acoustic panels with NRC ≥ 0.8

iii) Thermal

• Maintain: 22–24°C optimal range Humidity 40–60%

c. Biophilic Design

• Natural elements: Indoor greenery. Natural ventilation zones where safe visual access to daylight

d. Fatigue Reduction Layout

• Short walking distances between key functions

• Breakout zones every 30–50 meters

• Dedicated decompression spaces

Example : In a 24/7 operations office:

• Operators rotate every 2–3 hours

• Rest zones include: Low-light relaxation pods quiet recovery rooms

• Result: Reduced decision fatigue Improved alertness during critical shifts

A well-designed office improves decision-making speed, reduces human error, and enhances overall productivity.

5.0 MODULAR SOLUTIONS FOR REMOTE/FAST TRACK PROJECTS

Many oil and gas projects are located in remote or logistically challenging areas. Modular construction has become a game changer.

Modular construction is not just a construction method, it is a controlled manufacturing approach applied to building systems, especially valuable in oil & gas where time, safety, and quality consistency are critical.

5.1 Prefabricated Units Reduce On-Site Construction Risks

On-site construction in oil and gas environments often involves:

• Live plant interfaces

• Restricted access zones

• Hazardous operations nearby

• Weather exposure

• Simultaneous operations (SIMOPS)

Modularisation shifts high-risk work to a controlled fabrication environment.

5.2 Guidelines

a. Maximum Offsite Fabrication Strategy

• Target 60–90% prefabrication for: Office modules Control rooms Electrical rooms (MCC, switchgear rooms) HVAC skids

b. SIMOPS Risk Reduction

• Minimise hot works on site

• Reduce lifting operations in congested plant areas

• Limit workforce exposure in hazardous zones

c. Standardised Lifting and Transport Design

• Design modules based on: ISO container dimensions (w/a) Lifting points certified for offshore/onshore lifting

• Structural design must include: Temporary transport loads Crane lifting load factors (dynamic amplification)

Example : Instead of constructing a control building near a live refinery:

• Entire control room is fabricated in yard

• Tested for: Electrical systems HVAC balancing Fire alarm integration

• Delivered and installed via heavy lift crane in 1–2 days

5.3 Faster Deployment Timelines

Time is a critical cost factor in oil & gas projects.

Modular systems allow parallel execution:

• Site works proceed while modules are fabricated

• Commissioning preparation starts in factory phase

5.4 Guidelines

a. Parallel Engineering & Construction (Fast-Track EPCC)

• Engineering freeze early (to avoid rework),

• Offsite fabrication starts at 30–40% design completion,

• Site foundation works proceed simultaneously

b. Plug andPlay

• Pre-installed: Electrical cabling Data networks (fiber backbone) Fire protection piping HVAC ducting

d. Interface Management

Critical success factor:

• Define module-to-site interface control documents (ICDs)

• Ensure mechanical, electrical, and structural interfaces are standardized

Example : Timeline Comparison

6.0 IMPROVED QC IN FACTORY SETTINGS

Factory fabrication provides a controlled engineering environment, unlike unpredictable site conditions.

6.1 Guidelines

a. Factory Acceptance Test (FAT)

Before shipment:

• Electrical system energisation tests

• HVAC performance validation

• Fire alarm system simulation

• Network connectivity testing

b. Controlled Environmental Conditions

• Temperature-controlled welding areas

• Moisture-controlled curing of concrete modules

• Dust-free electrical panel assembly zones

c. Standardised QA/QC, (and Safety and Environment)

• ISO 9001 quality based systems (generic cross-reference to ISO 45001 and ISO 14001 or Intergrated Management Systems (IMS))

• Welding procedures qualified to ASME standards

• Traceability of materials via batch/heat numbers

d. Dimensional Accuracy Control

• Laser scanning / 3D metrology checks

• Tolerance control: Steel structure ±2–3 mm typical Module alignment verified before dispatch

Example : A prefabricated electrical control room:

• Fully wired in factory

• Tested under simulated load conditions

• Delivered with: Fully certified MCC panels Pre-configured SCADA interfaces Result:

• Zero on-site rewiring required

• Reduced commissioning time by ~40%

7.0 SCALABILITY FOR FUTURE EXPLANSION

Oil and gas facilities must adapt to:

• Production increases

• New digital systems

• Workforce expansion

• Regulatory changes

Modular design enables “building block” scalability.

7.1 Guidelines

a. Modular Grid-Based Design

• Use structural grid system (e.g. 6m x 6m or 3m x 6m modules)

• Allows: Horizontal expansion (add modules side-by-side). Vertical expansion (stacking where feasible)

b. Pre-Designed Expansion Interfaces

• Spare duct routes

• Reserved electrical capacity (e.g. 20–30% future load)

• Blank panel provisions for additional systems

c. Utility Oversizing Strategy

• HVAC systems designed with expansion margin

• Electrical switchgear with spare feeders

• Network systems with spare fiber cores

Example :

• Initial setup: 20-person control office module

• Future expansion: Scaled to 60-person operation by: Adding 2 additional modules Plugging into existing utility backbone No structural modification required

CONCLUSION

Building an oil and gas office is a multidisciplinary challenge that goes far beyond architecture. It is about engineering confidence into every detail from structural integrity to human comfort. With a strong EPCC framework, organisations can deliver facilities that are not only durable and efficient, but also aligned with the highest safety standards in the industry.
